DTL Bimetal Lug
Material: Expertly crafted with a combination of aluminum and copper, the DTL Bimetal Lugs ensure both compatibility and conductivity.
Share:
Product Description
Product Introduction:
DTL Bimetal Lugs are innovative electrical connectors designed to offer a dependable and efficient connection solution for aluminum and copper conductors. These lugs are essential in electrical applications where a secure and long-lasting connection between dissimilar metals is required.
Product Details:
- Material: Expertly crafted with a combination of aluminum and copper, the DTL Bimetal Lugs ensure both compatibility and conductivity.
- Chemical Treatment: The aluminum barrel undergoes a specialized chemical treatment that infuses it with a corrosion inhibitor, preventing oxidation and enhancing durability.
- Sealed Ends: The barrel ends are sealed to keep out dust and contaminants, further protecting the connection from environmental factors that could cause corrosion.
Structural Features:
- Bimetal Design: The lugs are constructed with both aluminum and copper components, providing a balanced and effective connection for dissimilar metals.
- Corrosion Inhibitor: A chemical treatment is applied to the aluminum barrel, which includes a corrosion inhibitor to prevent the onset of oxidation.
- Sealed Protection: The ends of the aluminum barrel are sealed to exclude environmental contaminants, ensuring the connector’s long-term integrity.
Advantages:
- Enhanced Longevity: The combination of chemical treatment and sealed ends significantly extends the functional lifespan of the DTL Bimetal Lugs.
- Reliability: These lugs provide a reliable connection that resists the common challenges of corrosion associated with connecting aluminum and copper conductors.
- Environmental Protection: By sealing the barrel ends, the lugs are better equipped to resist dust, moisture, and other environmental contaminants.
Installation Considerations:
- Ensure that the conductors are clean and prepared according to the manufacturer’s guidelines to maximize the effectiveness of the connection.
- Follow the recommended procedures for crimping or connecting the DTL Bimetal Lugs to the conductors to ensure a secure fit.
- Inspect the sealed ends before installation to confirm their integrity and that they are free from damage.
Specifications
| Type | ∅ | D | d | L | W | S |
|---|---|---|---|---|---|---|
| DTL-1-16 | 8.5 | 10 | 5.5 | 70 | 16 | 3 |
| DTL-1-25 | 8.5 | 12 | 7 | 75 | 18 | 3.5 |
| DTL-1-35 | 10.5 | 14 | 8.5 | 85 | 20 | 3.5 |
| DTL-1-50 | 10.5 | 16 | 9.5 | 90 | 23 | 4 |
| DTL-1-70 | 12.5 | 18 | 12 | 102 | 26 | 4.5 |
| DTL-1-95 | 12.5 | 21 | 13 | 112 | 28 | 5 |
| DTL-1-120 | 14.5 | 23 | 15 | 120 | 30 | 5.5 |
| DTL-1-150 | 14.5 | 25 | 16 | 126 | 34 | 6 |
| DTL-1-185 | 16.5 | 27 | 18 | 133 | 37 | 6.5 |
| DTL-1-240 | 16.5 | 30 | 20 | 140 | 40 | 7.5 |
Product Advantages
- 1.Galvanic Corrosion Resistance: The DTL Bimetal Lug is designed to resist galvanic corrosion, a common issue when aluminum and copper conductors are connected due to differences in electrochemical potential.
- 2.Strong Weld Intensity: Utilizing friction welding technology, these lugs provide a strong and secure connection, minimizing the risk of joint failure under load.
- 3.Chemical Treatment: The aluminum barrel is treated with a chemical process to prevent oxidation, ensuring the longevity and integrity of the connection.
- 4.Corrosion Inhibitor: The inclusion of a corrosion inhibitor within the aluminum barrel further enhances the resistance to environmental factors that could degrade the connection over time.
- 5.Dust Protection: The capped ends of the barrel protect the connection from dust and other contaminants, maintaining a clean and secure interface.
Application Places
- Power Distribution: Used in power distribution systems to connect aluminum cables to copper bus bars, ensuring efficient transmission of electricity.
- Electrical Equipment Termination: Ideal for terminating power supply cables to copper terminals in electrical equipment, providing a secure and corrosion-resistant connection.
- Utility Infrastructure: Employed in utility infrastructure for connecting cables to distribution equipment, enhancing the reliability of energy delivery.
- Renewable Energy Systems: Can be used in solar power systems or wind energy installations to connect aluminum support structures to copper conductors.
- Substation Connections: Utilized in electrical substations for connecting various components, ensuring a secure and reliable electrical interface.
